| PARTICULARS | UNIT | F I-100 | F I-150 | F I-200 | F I-300 | F I-400 | F I-600 | F I-800 | F I-1000 | F I-1200 |
|---|---|---|---|---|---|---|---|---|---|---|
| Capacity – Max | Kcal/hr | 100000 | 150000 | 200000 | 300000 | 400000 | 600000 | 800000 | 1000000 | 1200000 |
| Fuel Feeding Rate – max | Kg/hr | 25 | 36 | 49 | 73 | 98 | 147 | 195 | 243 | 293 |
| Power | HP | 0.5 | 0.5 | 1 | 2 | 2 | 3 | 3 | 5 | 7.5 |
| PLC Control Panel | YES | YES | YES | YES | YES | YES | YES | YES | YES | |
| Secondary fuel feeder | N/A | N/A | N/A | N/A | YES | YES | YES | YES | YES |
Fuel for our Burner – Wood Pellets
Pellet burners run on Wood/Agri-waste, carbon neutral & eco-friendly Pellets. Safe to store – No risks of hazards flexible in packages from 25 kg bag to 600 kg.
Option for fix rate yearly supply contract also.
| PARTICULARS | UNIT | Value |
|---|---|---|
| GCV | Kcal/kg | 4100 ± 2% |
| Ash % | % | <2-3% |
| Moisture % | % | <10 |
| Bulk Density | Kg/m3 | 600-730 |
Why Pellets are economical
| PARTICULARS | Pellet (Kg) | LPG (Kg) | LDO (Kg) | Diesel (Ltr) |
|---|---|---|---|---|
| Calorific value (Kcal) | 4100 | 12000 | 10200 | 9100 |
| Rate (Rs)** | 12-16 Max | 64 | 49 | 62 |
| Equivalent Pellet consumption | 2.9 | 2.5 | 2.2 | |
| Cost of Pellet (Rs) | 40 | 33 | 30 | |
| Tentative saving (Rs) | 24 | 16 | 32 | |
| Saving in % | 37% | 33% | 51% |
Benefits
- Eco friendly combustion
- Lower cost of fuel compared to Oil ( HSDA.DO/FO ) & Gas ( LPG / PNG / CNG / Propane )
- Minimum 30 to 50 % savings in fuel cost is guaranteed
- Easy to store, Handie and Transport
- Equal quality, un-interrupted availability of pellets @ all the seasons all over India
- Very small ash content ( Approx 2-3 % ) as residue after buming.
- Highly efficient ( 90-95 % 1 ) controlled combustion
- Low power consumption
- Clean & Silent operation
- Compact sized installation compared to Wood Gasifier
- Very few modification required to replace existing Oil & Gas bumer
WHY WE???
- PATENTED DESIGN
- Management is from qualified technocrat who have rich experience in combustion technology since 20 years.
- We have put up in – depth for 7 years to develop these products.
- Well organized & established Manufacturing facility
- Proven product as 400+ installations are done.
- Most of imported bumers do not successes here due to high Ash & moisture content in Indian wood / agri – waste compared to foreign countries
- As an additional service, we are also thinking contract to supply fixed rate, over the year and door delivery quality pellet supply on client’s demand anywhere in India.
Features
- # Colorful Touch screen PLC Control
- # Graphical Display : Large graphical display ensure un – interrupted operation of the unit
- # Large fonts & Icons : Make easy to operate
- # Password based setting data : Allows only authorised persons to change setting parameters
- # Detailed Home page : Shows set temp. Actual temp, run time of Burner, running pellet consumption total consumption of the day & many more
- # Auto, Manual & Test mode operations : Facilitate operator to control all situations
- # PDI controlled modulation system
- # VFD driven proper Air – Fuel ration control system
- # Fuse n relay based safety features
- # Alarm hooter for Low fuel warning system
- # Socket connector type Plug n play system for easy of installation
- # Additional controls for Semi Auto and manual system
- # All proven and branded hardware we use in Control Panel
Biomass
Continuous significant increase in prices of liquid & Gaseous fuels is increasing interest in lot of cheaper, alternative sources of energy everywhere. We are glad to offer our range of Burners at RE GREENFIRE, allows you to effectively burn renewable fuel i.e. wood Pellets. The relatively low price of Bio – Fuels can save up to 50 % in fuel costs.
Wood Pellets
Pellets are formed by compressing the saw dust / agri raw material at high pressure, without any chemical adhesives. Pellet fuel is environment friendly and also easy to transport, to store and to distribute. They are characterized by allowing moisture content, low ash and they are not harmful to the environment as carbon neutral fuel and they are having high energy value.
APPLICATION
These products are proven out – come of our in depth R & D efforts and it can be useful as cheaper heating solution at steam boilers, Thermic fluid, heaters. Hot air Generators, Hot water generators, Bakery ovens, Asphalt Batch – Mix Plants, Chemical Industries, Pharmaceutical Printing and many more industries.
